Huawei SmartAX MA5608T Hardware Description

Differences Between 24-channel VDSL SPL Boards
Table 3-201 lists the major differences between 24-channel VDSL SPL boards.
Table 3-201 Major differences between 24-channel VDSL SPL boards
Board Port Impedance Applicable
Line
Applicable
Service Board
H801VSTL Complex impedance (ETSI TS 101 952
01 01 option A)
POTS 24-port VDSL2
over POTS
Service Board
H801VSTH Complex impedance (2B1Q or 4B3T) ISDN 24-port VDSL2
over ISDN
Service Board
Differences Between 48/64-channel VDSL SPL Boards
Table 3-202 lists the major differences between 48/64-channel VDSL SPL boards.
Table 3-202 Major differences between 48/64-channel VDSL SPL boards
Board
Port
Quanti
ty
Port Impedance Applicable
Line
Applicable
Service
Board
H801VSN
F
48 600-ohm impedance POTS 48-port
VDSL2 over
POTS
Service
Board
H801VSN
LA
48 Complex impedance (ETSI TS 101
952 01 01 option A)
POTS 48-port
VDSL2 over
POTS
Service
Board
H801VSP
HA
64 2B1Q or 4B3T ISDN 48/64-port
VDSL2 over
ISDN
Service
Board
H801VSP
LA
64 Complex impedance (ETSI TS 101
952 01 01 option A)
POTS 64-port
VDSL2 over
POTS
Service
Board
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
803

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
