Huawei SmartAX MA5608T Hardware Description

DIP Switch Settings (5, 4, 3,
2, 1)
Addres
s Value
DIP Switch Settings (5, 4, 3,
2, 1)
Addres
s Value
00100 4 10100 20
00101 5 10101 21
00110 6 10110 22
00111 7 10111 23
01000 8 11000 24
01001 9 11001 25
01010 10 11010 26
01011 11 11011 27
01100 12 11100 28
01101 13 11101 29
01110 14 11110 30
01111 15,
default
11111 31
NOTE
When S6-1 to S6-5 are used to set the subnode address, make sure that the DIP switch settings are
consistent with the data configuration. The address value cannot be 30. The subnode address value
cannot be the same as that of the monitoring board of the fan tray.
Specification
Table 6-9 shows the specification of the I-type DC PDU.
Table 6-9 Specification of the I-type DC PDU
Item
Specification
Dimensions (W x D x H, excluding
mounting brackets)
490 mm x 231.2 mm x 97.2 mm
Weight 5.3 kg
Output tributary quantity 8
Input voltage -48 V (-38.4 V to -57.6 V)
/-60 V (-38.4 V to -72 V)
Maximum input current 120 A
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
6 Electromechanical Device
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
918

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
