Number of Rectifier Modules Maximum Output Current
5 75 A
LED Description
Table 6-23 describes the LEDs on the rectifier module of the EPS75-4815AF power system.
Table 6-23 LEDs on the rectifier module of the EPS75-4815AF power system
LED
Status Description
RUN The green LED is on. The rectifier module works in the normal
state.
The green LED is off. This LED is off when the red LED is on or
the yellow LED is on which is not caused by
the output overcurrent.
ALM The yellow LED is on. An alarm has been generated for the rectifier
module. The possible causes are as follows:
l The AC power is cut off or no AC power
is supplied.
l Over-temperature protection is enabled.
l Primary protection is enabled.
Specifically, the rectifier module
automatic protection function is enabled
due to a high voltage on the AC input
end.
l Overcurrent protection is enabled.
Specifically, the rectifier module
automatic protection function is enabled
because the DC output current of the
rectifier module exceeds the current
range supported by the rectifier module.
The yellow LED blinks. The communication of the rectifier module
is interrupted.
The yellow LED is off. The rectifier module works in the normal
state.
FAULT The red LED is on. The rectifier module is faulty. The possible
causes are as follows:
l The AC power supply is faulty.
l The output voltage is 0 V.
l The fan is faulty.
l The rectifier module output is short-
circuited or does not work.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
6 Electromechanical Device
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
937
