Huawei TE20 - Conference Control

TE20 Videoconferencing Endpoint
Administrator Guide
3 Conference Operations Using the Remote Control
Issue 01 (2016-09-01)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
18
Procedure
Step 1 On the main menu, press any number key on the remote control.
The Speed Dial page is displayed, as shown in Figure 3-1.
Step 2 Enter the domain name (example: HUAWEI_TE20.vmr@videxio.com) of a virtual
conference room in the text box, or a remote site URI (example: TE20GZ).
Step 3 Press the button on the remote control, switch to , and press the on the remote
control.

If no password is set for the conference, the endpoint joins the conference directly.

If a password is set for the conference, perform operations in Step 4 and Step 5.
Step 4 Press any number key on the remote control.
The Two-Stage Dialing dialog box is displayed.
Step 5 Enter a conference password to join the conference.
----End
3.3 Conference Control
Background
In a multi-point conference, you can manage the images and sound of participants.
In a multi-point conference initiated via the MCU (such as VP9660), you can perform
conference and site control operations listed in Table 3-1.
Operations, including Release Chair, Add Site, Call Site, Mute/Unmute MIC, Broadcast Site, and
Disconnect Site, can be performed only after you obtaining chair control rights.
Table 3-1 Conference and site control operations
Confere
nce
control
Request Chair, Release Chair, Extend Conference
Site
control
Add Site, Call Site, Mute/Unmute MIC, View Site, Broadcast Site, and
Disconnect Site
Accessing the Conference Control Screen
Perform the following operations to access the Conference Control screen:
Step 1 To access the menu screen, press the button on the remote control.
Step 2 Press the button on the remote control, and switch to .
