18
Representative connection examples are explained below.
z Connecting the teaching pendant directly to the controller (Parallel connection with the PLC)
(a) Connecting multiple controllers (8 units or less) using a single power supply
Short the MPI and MPO terminals using a jumper wire. (The controller is shipped with these terminals
shorted.)
Connect one end of the EMG signal to the 24-V output of the input power supply and the other end to
the S1 terminal.
Then, provide connections by sequentially connecting the S2 terminal of controller 1 to the S1 terminal of
controller 2, the S2 terminal of controller 2 to the S1 terminal of controller 3, and so on, and connect the
S2 terminal on the last controller to the EMG terminals on all controllers.
Use a relay terminal block for connection to the EMG terminals.
(Note) Do not connect two or more wires to one terminal.
