Table 20. Controller numeric display diagnostic codes (continued)
Value Description
LE Uncertified cache memory DIMM sizes
LF Lockdown with limited SYMbol support
LH Controller firmware mismatch
Table 21. ESM numeric display diagnostic codes
Value Description
_ _ ESM Boot Diagnostic is running
88 This ESM is being held in Reset by the other
ESM
AA ESM-A application is booting up
bb ESM-B application is booting up
L0 Mismatched ESM types
L2 Persistent memory errors
L3 Persistent hardware errors
L9 Over Temperature
LL Cannot read midplane EEPROMs
LP Missing Drive Port Mapping table
Ln ESM not valid for enclosure
H2 Invalid/Incomplete Configuration
LF Lockdown with limited SYMbol support
LH Controller firmware mismatch
H3 Maximum Reboot Attempts Exceeded
H4 Cannot Communicate with Other ESM
H5 Midplane Harness Failure
H6 Firmware Failure
H9 Non-Catastrophic HW. ESM operational, but
in a degraded mode
J0 Incompatible module
Chapter 6. Solving problems 173
