v Remove the device from its package and install it directly into the system unit
without setting it down. If it is necessary to set down the device, put it back into
its static-protective package. Do not place the device on the system unit cover or
on a metal surface.
v Take additional care when you handle devices during cold weather. Heating
reduces indoor humidity and increases static electricity.
Preparing for installation
This topic prepares you for the DS3500 storage subsystem and the EXP3500 storage
enclosure installation.
Before you install the DS3500 storage subsystem, create a detailed plan of how the
device will be used in the storage configuration. The plan should include RAID
levels, failover requirements, operating systems that are to be used, and total
storage capacity requirements.
To prepare the DS3500 storage subsystem for installation in a rack, complete the
following steps:
1. Prepare the site for installation. For more information, see “Specifications” on
page 17.
2. Move the shipping box that contains the DS3500 to the site.
CAUTION:
or
>18 kg (39.7 lb)
or
18-32 kg (39.7-70.5 lb)
The weight of this part or unit is between 18 and 32 kg (39.7 and 70.5 lb). At
least two individuals are required to safely lift this part or unit. (C009)
3. Ensure that you have the correct host software for your operating system.
The support DVD that is shipped with the DS3500 has the correct Storage Manager
host software. The DVD also includes the storage subsystem controller firmware.
For the latest controller firmware, see http://www.ibm.com/servers/storage/
support/disk/.
4. Read the applicable readme files that are included in the Storage Manager host
software or DS3500 controller firmware packages for any updated information
about hardware, software, or firmware products.
5. Continue with “Required tools and hardware.”
Required tools and hardware
The tools and hardware that are required to install the DS3500 storage subsystem
are listed here.
Keep the following tools and equipment ready:
v Region-specific power cords
v 5/16 (8 mm) hex nut driver
v #0 and #1 Phillips screwdrivers
v Electrostatic-discharge protection (such as a grounding wrist strap)
28 IBM System Storage DS3500 and EXP3500 Storage Subsystem: Installation, User's, and Maintenance Guide
