Table 23. Parts listing for the DS3524 storage subsystem and EXP3524 storage enclosure
storage subsystem (continued)
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU part
number
6 Controller or environmental service module
filler panel
69Y0194
7 Power supply, AC (models C4A and E4A) 00W1521
Power supply, DC (models C4T and E4T) 00W1522
8 Host interface adapter, 6 Gbps SAS 2-port 69Y2840
Host interface adapter, 8 Gbps FC 4-port 69Y2841
Host interface adapter, 1 Gbps iSCSI 4-port 69Y2842
Host interface adapter, 10 Gbps iSCSI 2-port 81Y9943
9 Filler panel, host port adapter 69Y2897
10 Controller with 1 GB DIMM, no host port
expansion adapter, no backup battery
module.
68Y8481
DIMM, 2 GB cache memory 69Y2843
Flash memory, cache backup, 8 GB 90Y8691
Backup battery module 69Y2926
IBM 1-meter mini-SAS cable 39R6530
IBM 3-meter mini-SAS cable 39R6532
Service cable 13N1932
Power cord, rack jumper, 2.8-meter (models
C4A and E4A)
39M5377
Power cable, dc, 4.0-meter (models C4T and
E4T)
81Y9590
Miscellaneous rack mounting hardware kit 39R6551
Environmental service module 69Y0189
8 GB shortwave SFP transceiver 49Y4123
Power cords
For your safety, IBM provides a power cord with a grounded attachment plug to
use with this IBM product. To avoid electrical shock, always use the power cord
and plug with a properly grounded receptacle.
IBM power cords used in the United States and Canada are listed by Underwriter's
Laboratories (UL) and certified by the Canadian Standards Association (CSA).
For units intended to be operated at 115 volts: Use a UL-listed and CSA-certified
cord set consisting of a minimum 18 AWG, Type SVT or SJT, three-conductor cord,
a maximum of 15 feet in length and a parallel blade, grounding-type attachment
plug rated 15 amperes, 125 volts.
For units intended to be operated at 230 volts (U.S. use): Use a UL-listed and
CSA-certified cord set consisting of a minimum 18 AWG, Type SVT or SJT,
Chapter 7. Parts listing, DS3500 storage subsystem and EXP3500 storage enclosure 179
