IBM DS3500 User Manual

Table 22. Parts listing for the DS3512 storage subsystem and EXP3512 storage enclosure
storage subsystem
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU part
number
1 DS3512 and EXP3512 bezel kit 69Y0203
2 Filler panel, 3.5–inch drive 42D3315
3 Hard disk drive, 3.5-inch 300 GB 15,000 rpm
LFF SAS
49Y1860
Hard disk drive, 3.5-inch 450 GB 15,000 rpm
LFF SAS
49Y1865
Hard disk drive, 3.5-inch 600 GB 15,000 rpm
LFF SAS
49Y1870
Hard disk drive, 3.5-inch 600 GB 15,000 rpm
LFF SAS SED
49Y1983
Hard disk drive, 3.5-inch 1 TB 7,200 rpm
LFF NL-SAS
49Y1880
Hard disk drive, 3.5-inch 2 TB 7,200 rpm
LFF NL-SAS, T10 PI capable
90Y9000
Hard disk drive, 3.5-inch 3 TB 7,200 rpm
LFF NL-SAS, T10 PI capable
81Y9878
4 2U rail kit 39R6550
5 DS3512 and EXP3512 midplane 69Y0249
6 Controller or environmental service module
filler panel
69Y0194
Figure 127. DS3512 storage subsystem and EXP3512 storage enclosure storage subsystem
parts
176 IBM System Storage DS3500 and EXP3500 Storage Subsystem: Installation, User's, and Maintenance Guide
