IBM N51 Series User Manual

(CONTINUED)
014 (continued)
IS THE CONFIGURATION THE SAME AS THE
INSTALLED DEVICES?
Yes No
015
– Go to “Checking the Installed Devices List” on
page 358.
016
– Select Start and press Enter.
Diagnostic tests will run on all available devices.
If the test find any device errors, the errors are displayed
with an X beside the device name.
For example:
DID THE TESTS FIND A DEVICE ERROR?
Yes No
017
The error was not detected by the basic test. Go to
Step 019.
018
– Note the error codes and go to “FRU Codes” on
page 356 and replace the appropriate FRUs.
019
– Go to the advanced diagnostic screen by pressing
Ctrl+A, and run the following tests.
 Diskette drive test (use a blank diskette).
 Serial port test (with the wrap plug).
Note: Install the wrap plug on the serial port of the
Dock I.
 Parallel port test (with the wrap plug).
Note: Install the wrap plug on the parallel port of
the Dock I.
 Keyboard test (see “How to Run the Keyboard
Test” on page 360).
(Step 019 continues)
SystemBoard
02
FRU
0010
DEV 001
ERR
DEV: Device ID
ERR: Error Description Code
FRU: FRU Code
Note: If the test stops or
hangs during the test,
replace the last device
that was tested.
344 IBM Mobile Systems HMM - Volume 1
