Index Number FRU Part
Number
Units Per
Assembly
Description
1 00P3210 1 Operator Panel
2 See Note 1 SCSI Media Device (50-Pin)
3 See Note 1 SCSI Media Device (68-Pin)
4 See Note 1 SCSI Media Device (68-Pin)
5 09P5870 1 CEC Backplane to Operator Panel Signal / Power Cable
5 00P3791 1 Operator Panel Extension Cable (7028 Model 6E4 Only)
5 00P3822 1 Operator Panel Interposer (7028 Model 6E4 Only)
6 92F0324 1 SCSI Media 50-pin to 68-pin Converter Cable
(Transposer)
7 09P5862 1 Integrated SCSI Media Device Signal Cable
8 09P5863 1 CEC Backplane Connector to Diskette Drive Signal Cable
9 09P5868 1 CEC Backplane to IDE CD-ROM Signal Cable
10 See Note 1 Diskette Drive
11 See Note 1 IDE CD-ROM
12 00P4132 1 Disk Drive Backplane
13 09P5895 1 PCI Riser Card to Disk Drive Backplane Signal Cable (50
pin)
14 09P5889 1 PCI Riser Card to Disk Drive Backplane Signal Cable (68
pin)
15 09P5290 1 6-Slotted PCI Riser Card
15a 00P4483 1 4-Slotted PCI Riser Card
16
00P4488 1
CEC Backplane
00P5830 1
17 09P5869 1 PCI Riser Card to External SCSI Signal Cable
18 N/A 1 External SCSI Port
19 09P5899 1 CEC Backplane to Rack Indicator Signal Cable
20 N/A 1 Rack Indicator Port
21 00P3200 1 CEC Backplane to Debug Port Signal Cable
22 N/A 1 Debug Parallel Port
Note: See RS/6000 Eserver pSeries Diagnostic Information for Multiple Bus Systems for part numbers.
Chapter 10. Parts Information 525
