Table 24 on page 138lists the specifications for the IBM 24/10-Port SAN Extension Module.
Description Specification
Environmental Requirements
Temperature, certified for operation (module intake of
ambient)
32 to 104° F (0 to 40° C)
Temperature, ambient nonoperating and storage -40 to 158° F (-40 to 70° C)
Humidity (RH), ambient (noncondensing) operating 5 to 90%
Altitude, designed and tested for operation -197 to 6500 ft (-60 to 2000 m)
Physical Characteristics
Dimensions 1.75 x 15.9 x 21.8 in. (4.4 x 40.39 x 55.37 cm)
Weight 17 lb (7.7 kg)
Table 24. Extension ModuleSpecifications
Table 25 on page 138 lists the specifications for the IBM c-type SAN 48-Port 32-Gbps FC Switching
Module.
Description Specification
Environmental Requirements
Temperature, certified for operation (module intake of
ambient)
32 to 104° F (0 to 40° C)
Temperature, ambient nonoperating and storage -40 to 158° F (-40 to 70° C)
Humidity (RH), ambient (noncondensing) operating 10 to 90%
Altitude, designed and tested for operation -197 to 6500 ft (-60 to 2000 m)
Physical Characteristics
Dimensions 1.75 x 15.9 x 21.8 in. (4.4 x 40.39 x 55.37 cm)
Weight 17.5 lb (7.94 kg)
Table 25. IBM c-type SAN 48-Port 32-Gbps Fibre Channel Switching ModuleSpecifications
Power Specifications for the IBM c-type SAN Director
This section includes the following topics:
• “Power Supply Specifications ” on page 138
• “Component Power Requirements and Heat Dissipation” on page 140
• “AC Power Consumption for the SAN768C-6 Director” on page 141
• “AC Power Consumption for the SAN384C-6 Director” on page 142
• “AC Power Consumption for the SAN192C-6 Director” on page 142
• “AC Power Supply Requirements for Grid Redundancy” on page 143
Power Supply Specifications
Table 26 on page 139 lists the specifications for the SAN c-type Director power supplies.
138IBM Storage Networking SAN192C-6, SAN384C-6 and SAN768C-6: SAN192C-6, SAN384C-6 and
SAN768C-6 Installation, Service, and User Guide
