IBM SAN192C-6 - AC Power Consumption for the SAN768 C-6 Director; Dissipation for 3000 W AC Power Supplies for Different Solutions with 32-G Fibre Channel Ports; Consumption for SAN768 C-6 Director

Power Required (watts)Module Type/ Product
Number
Quantity
Maximum Typical
SAN768C-6 Fan Module 900 75
SAN384C-6 Crossbar
Switching Fabric1 Module
600 50
SAN192C-6 Fan Module
3
300 40
Table 27. Requirements for 3000 W AC Power Supplies (continued)
Power Required (watts)
Number of
Switching Modules Number of Ports Typical Total Worst Case
Heat Dissipation
(BTU/hr)
1 48 1440 3430 12861
2 96 1700 3780 14173
3 144 1960 4130 15486
4 192 2220 4480 16798
5 240 2480 4830 18111
6 288 2740 5180 19423
7 336 3000 5530 20735
8 384 3260 5880 22048
Table 28. Dissipation for 3000 W AC Power Supplies for Different Solutions with 32-G Fibre Channel ports using
IBM c-type SAN 48 port 32Gbps Switching Module and six Fabric Modules.
AC Power Consumption for the SAN768C-6 Director
Table 29 on page 141 shows the typical AC power consumption for the SAN768C-6 Director.
Typical AC Power Consumption (Watts)
Speed/Module
Type
Number of
Fabric Modules 192 ports 288 ports 384 ports 768 ports
32-G Fibre
Channel ports
with SAN c-type
48-port 32-
Gbps Switching
Module
6 2545 3065 3585 5665
Table 29. Consumption for SAN768C-6 Director
Appendix A. Product Specifications141
