Description Specification
3000-W AC Power Supply
Type Autoranging input with power factor corrector.
Voltage 100 to 240 VAC (+ or - 10%).
Current rating 16 A maximum at 100 to 120 VAC and 1451-W
output. 16 A maximum at 200 to 240 VAC and 3051-
W output.
For current ratings of plugs, see Figure6-3 on page
6-154 .
Frequency 50 to 60 Hz (nominal) (+ or - 3 Hz for full range).
Output capacity 1451 W maximum (100 to 120 VAC, 1400W available
to chassis)
3051 W maximum (200 to 240 VAC, 3000W available
to chassis)
Output voltage at 110/120 3.4V (+/- 4%) at 15A; 50V(+/- 4%) at 28A.
Output voltage at 200/240 3.4V (+/- 4%) at 15A; 50V(+/- 4%) at 28A
Efficiency >94% at 50% load
ITHD <5.1% at 50% load
3500-W High Voltage AC/DC Power Supply (SAN192C-6 and SAN384C-6)
Type Autoranging input with power factor corrector.
Input Voltage Range 120 VAC nominal low-line mode (85 to 132 VAC)
240 VAC nominal high-line mode (170 to 264 VAC)
277 VAC nominal high line mode (188 to 305 VAC)
240 VDC nominal high-line mode (192 to 288 VDC)
380 VDC nominal high-line mode (260 to 400 VDC)
Input Current 20A service, 16A maximum at nominal line voltage
(240 or 277 VAC)
20A service, 16A maximum at nominal line voltage
(240 or 380 VDC)
Input Frequency 47 to 63 Hz
Table 26. SAN c-type Director Power Supplies
Appendix A. Product Specifications139
