LED Status Description
Amber One of the following problems
has occurred:
• Any power supply unit LED is
red.
• Any power supply unit is down.
Green Fan modules are operational.FAN
Amber At least one I/O module has a red
STATUS LED.
Green Supervisor modules are
operational.
SUP
Amber At least one I/O module has a red
STATUS LED.
Green Fabric modules are operational.FAB
Amber At least one I/O module has a red
STATUS LED.
Green Switching modules are
operational.
IOM
Amber At least one I/O module has a red
STATUS LED.
Table 2. IBM c-type SAN switches and directors System LEDs (continued)
Supervisor Modules
This section describes supervisor modules supported by different IBM c-type SAN switches and directors:
• “IBM Supervisor-4 Module” on page 12
• “IBM Supervisor-1E Module” on page 16
• “IBM Supervisor-1 Module” on page 20
IBM Supervisor-4 Module
The Supervisor-4 Module is designed specifically for the SAN768C-6, SAN384C-6 and SAN192C-6
directors. This supervisor module delivers the latest advanced switching technology and resources.
The IBM c-type SAN director Supervisor-4 Module provides control and management functions for the
IBM c-type SAN Directors and enables intelligent, resilient, scalable, and high-performance multilayer
SAN switching. The IBM c-type SAN director Supervisor-4 Module is supported on the SAN768C-6,
SAN384C-6 and SAN192C-6 Multilayer Directors. The IBM c-type SAN director Supervisor-4 Module is
supported from NX-OS Release 8.4(1) or later on the IBM SAN384C-6 and the IBM SAN192C-6, and NX-
OS Release 8.4(2a), or later, on the IBM SAN768C-6.
This supervisor module supports the following features:
• Supports up to 768 4/8/16/32-Gbps Fibre Channel ports in a single SAN768C-6 Multilayer Director
chassis
12IBM Storage Networking SAN192C-6, SAN384C-6 and SAN768C-6: SAN192C-6, SAN384C-6 and
SAN768C-6 Installation, Service, and User Guide
