SFP+ Transceiver Specifications
The IBM SAN c-type Directors are compatible with SFP+ transceivers and cables that have LC connectors.
The wavelength of each transceiver must match the transceiver on the other end of the cable, and the
cable must not exceed the stipulated cable length for reliable communications.
SFP+ transceivers provide the uplink interfaces, laser transmit (Tx) and laser receive (Rx), and support
850 to 1610 nm nominal wavelengths, depending upon the transceiver.
Use only Cisco SFP+ transceivers on the SAN c-type Directors. Each SFP+ transceiver is encoded with
model information that enables the switch to verify that the SFP+ transceiver meets the requirements for
the switch.
This section provides the following topics:
• “Fibre Channel SFP+ Transceivers” on page 144
Fibre Channel SFP+ Transceivers
Table 33 on page 144 lists the Fibre Channel transceivers.
Description Type
32 Gbps Fibre Channel SW SFP+ Short wavelength
32 Gbps Fibre Channel LW SFP+ Long wavelength
16 Gbps Fibre Channel SW, SFP+ Short wavelength
16 Gbps Fibre Channel LW, SFP+ Long wavelength
8 Gbps Fibre Channel SW, SFP+ Short wavelength
8 Gbps Fibre Channel LW, SFP+ Long wavelength
8 Gbps Fibre Channel ER SFP+ Extended Reach
8-Gbps Fibre Channel CWDM SFP+ Coarse Wavelength-Division Multiplexing (CWDM)
10GBASE-SR SFP Module Short Reach
10GBASE-LR SFP Module Long Reach
10GBASE-ER SFP Module Extended Reach
10GBASE-DWDM SFP+ Dense Wavelength- Division Multiplexing (DWDM).
40 different wavelengths are offered
[1]
(Technical
Specifications).
32 Gbps Fibre Channel ELW SFP+ Extended Long wavelength
16 Gbps Fibre Channel ELW SFP+ Extended Long wavelength
1000BASE-SX SW SFP GbE MMF Short wavelength
Table 33. Fibre Channel transceivers
144IBM Storage Networking SAN192C-6, SAN384C-6 and SAN768C-6: SAN192C-6, SAN384C-6 and
SAN768C-6 Installation, Service, and User Guide
