IBM SAN192C-6 User Manual

LED Status Description
Green The management port link is
operational.
Link
Off No link signal received.
Green The log flash CompactFlash or
USB disk is being accessed. Do
not remove the media until the
LED is off..
LOG FLASH
Off The expansion flash
CompactFlash or USB disk is not
being accessed. You can remove
the media while this LED is off.
Green The log flash CompactFlash or
USB disk is being accessed. Do
not remove the media until the
LED is off.
Slot0
Off The expansion flash
CompactFlash or USB disk is not
being accessed. You can remove
the media while this LED is off.
Table 4. IBM Supervisor-1E Module LEDs (continued)
IBM Supervisor-1 Module
The IBM Supervisor-1 Module is designed specifically for the SAN192C-6 and SAN384C-6 chassis.
This supervisor module provides control and management functions for the switch and enables high-
performance switching.
This supervisor module supports the following features:
• Nondisruptive software upgrades
• Stateful process restart and failover
• Fully redundant operation
• Support for up to 384 Fibre Channel ports in a single chassis and 1152 Fibre Channel ports in a single
rack
• Support for up to 24 Tbps of Fibre Channel system bandwidth
• Multipathing based on Fabric Shortest Path First (FSPF)
• Ability to dynamically reroute traffic in the event of a switch failure
• Network management through the command-line interface (CLI) and through Data Center Network
Manager (DCNM)
• Extensive security features including RADIUS and TACACS+, Fibre Channel Security Protocol (FC-SP),
Secure File Transfer Protocol (SFTP), Secure Shell (SSH) Protocol, and Simple Network Management
Protocol Version 3 (SNMPv3) implementing Advanced Encryption Standard (AES), VSANs, hardware-
enforced zoning, ACLs, and per-VSAN role-based access control
• Support for virtual SAN (VSAN) technology and inter-VSAN routing (IVR)
• Network services such as access control lists (ACLs) and quality of service (QoS)
• Smart zoning
20IBM Storage Networking SAN192C-6, SAN384C-6 and SAN768C-6: SAN192C-6, SAN384C-6 and
SAN768C-6 Installation, Service, and User Guide

IBM SAN192C-6 Specifications

General

Brand	IBM
Model	SAN192C-6
Category	Storage
Language	English
