IBM SAN192C-6 User Manual

Description Specification
Output capacity 1500 W maximum (100 to 120VAC) 3100 W
maximum (200 to 210VAC)
3500 W maximum (215 to 240 and 277VAC)
3100 W maximum (200 to 215VDC)
3500 W maximum (220 to 380VDC)
Table 26. SAN c-type Director Power Supplies (continued)
Component Power Requirements and Heat Dissipation
When sizing the air-conditioning requirements for an installation, consider heat dissipation. The power
and heat associated with an IBM SAN c-type Directors varies based upon the following considerations:
• Power supply type
• Switching module type and number of switching modules installed
• Average switching traffic levels
Table 27 on page 140 lists the power requirements for the components of the SAN c-type Director.
Note: Unless noted otherwise, the power requirement data listed under the Maximum Power Required
column in Table 27 on page 140 is based on the worst-case conditions that are unlikely in a data center
environment.
Power Required (watts)Module Type/ Product
Number
Quantity
Maximum Typical
SAN c-type Director 48
port 32Gbps Switching
Module
350 260
24/10 port SAN Extension
Module
4 (SAN192C-6)
8 (SAN384C-6)
16 (SAN768C-6)
480 450
SAN c-type Supervisor-4
Module
120 110
SAN c-type Director
Supervisor-1E Module
265 160
SAN c-type Director
Supervisor-1 Module
2
190 110
SAN768C-6 Crossbar
Switching Fabric1 Module
300 160
SAN384C-6 Crossbar
Switching Fabric1 Module
150 135
SAN192C-6 Crossbar
Switching Fabric1 Module
85 64
SAN384C-6 Crossbar
Switching Fabric3 Module
150 135
SAN192C-6 Crossbar
Switching Fabric3 Module
6
85 64
Table 27. Requirements for 3000 W AC Power Supplies
140IBM Storage Networking SAN192C-6, SAN384C-6 and SAN768C-6: SAN192C-6, SAN384C-6 and
SAN768C-6 Installation, Service, and User Guide
