IBM SAN192C-6 - AC Power Consumption for the SAN384 C-6 Director; AC Power Consumption for the SAN192 C-6 Director; Consumption for SAN384 C-6 Director; Consumption for SAN192 C-6 Director

Typical AC Power Consumption (Watts)
Speed/Module
Type
Number of
Fabric Modules 192 ports 288 ports 384 ports 768 ports
16-G Fibre
Channel ports
with SAN c-type
48-port 32-
Gbps Switching
Module
2545 3065 3585 5665
Table 29. Consumption for SAN768C-6 Director (continued)
AC Power Consumption for the SAN384C-6 Director
Table 30 on page 142 shows the typical AC power consumption for the SAN384C-6 Director.
Typical AC Power Consumption (Watts)
Speed/Module Type
Number of Fabric
Modules 192 ports 288 ports 384 ports
32-G Fibre Channel
ports with SAN c-
type 48-port 32-
Gbps Switching
Module
6 2220 2740 3260
16-G Fibre Channel
ports with SAN c-
type 48-port 32-
Gbps Switching
Module
3 1815 2335 2855
Table 30. Consumption for SAN384C-6 Director
AC Power Consumption for the SAN192C-6 Director
Table 31 on page 142 shows the typical AC power consumption for the SAN192C-6 Director.
Typical AC Power Consumption (Watts)
Speed/Module Type
Number of Fabric
Modules 96 ports 192 ports
32-G Fibre Channel ports
with SAN c-type 48-
port 32 Gbps Switching
Module
6 1244 1764
16-G Fibre Channel ports
with SAN c-type 48-
port 32-Gbps Switching
Module
3 1052 1572
Table 31. Consumption for SAN192C-6 Director
142IBM Storage Networking SAN192C-6, SAN384C-6 and SAN768C-6: SAN192C-6, SAN384C-6 and
SAN768C-6 Installation, Service, and User Guide
