The SAN192C-6 supports up to 192 ports in a 6-slot modular chassis, with up to 768 ports in a single
rack. The ports can be configured as Fibre Channel (4/8/16 Gbps, or 8/16/32 Gbps). The SAN192C-6
supports the same Fibre Channel switching modules as the SAN768C-6 and SAN384C-6 for a high degree
of system commonality.
The following are the major features offered by SAN192C-6.
• Up to 6 x 512 x 4 slots = 12.288-Tbps per chassis Fibre Channel switching bandwidth
• Comprehensive security features
• Intelligent network services, including VSAN technology, IVR, and smart zoning
• SAN management tools including Data Center Network Manager (DCNM) and the command-line
interface (CLI)
• Online diagnostics (GOLD, Call Home, and so on)
• Multiprotocol architecture, including Fibre Channel
Supported Components
• “Supported Components on the SAN768C-6 ” on page 3
• “Supported Components on the SAN384C-6” on page 3
• “Supported Components on the SAN192C-6” on page 4
Supported Components on the SAN768C-6
The SAN768C-6 director supports the following components:
• SAN768C-6 Chassis
• IBM c-type SAN Director Supervisor-4 Module
• IBM c-type SAN switches and directors Supervisor-1E Module
• IBM c-type SAN switches and directors Fabric-1 Switching Module
• IBM c-type SAN Director 48 Port 32 Gbps Fibre Channel Switching Module
• IBM c-type SAN Director 24/10 port SAN Extension module
• SAN768C-6 Crossbar Switching Fabric-1 Module
• SAN768C-6 Crossbar Switching Fabric-3 Module
• SAN768C-6 Fan Module
• IBM c-type SAN Director 3000W AC power supply
• SAN768C-6 Accessory Kit
Supported Components on the SAN384C-6
The SAN384C-6 Director supports the following components:
• SAN384C-6 Chassis
• IBM c-type SAN Director Supervisor-4 Module
• IBM c-type SAN Director Supervisor-1 Module
• IBM c-type SAN Director 48 Port 32 Gbps Fibre Channel Switching Module
• IBM c-type SAN Director 24/10 port SAN Extension module
• SAN384C-6 Crossbar Switching Fabric-1 Module
• SAN384C-6 Crossbar Switching Fabric-3 Module
• SAN384C-6 Fan Module
• IBM c-type SAN Director 3000W AC power supply
• SAN384C-6 Accessory Kit
Chapter 1. Introducing the IBM c-type SAN Directors3
