IBM SAN192C-6 - Supported Plugs for 3000 W AC Power Supplies

LengthDescription
Feet Meters
Power Cord, 250VAC 20A NEMA, 6-20 Plug, USA 13.12 4
Power Cord, 250VAC 20A NEMA L6-20 Twist Lock Plug, USA 13.58 4.14
Power Cord, 250VAC 16A CEE 7/7 Plug, EU 13.12 4
Power Cord, 250VAC 16A IEC 309 Plug, International 13.58 4.14
Power Cord, 250VAC 16A SEV 1011 Plug, Switzerland 8 2.44
Power Cord, 250VAC SABS 1661 Plug, South Africa 14 4.27
Power Cord, 250VAC 16A SI16S3 Plug, Israel 14 4.27
Power Cord 250VAC 16A, Src Plug EL224-C19, Brazil, 14 4.27
Power Cord 250VAC 16A, Src Plug IR2073-C19, Argentina, 14 4.27
Table 47. Power Cords for the IBM c-type Director (continued)
Supported Plugs for 3000 W AC Power Supplies
Figure 41 on page 154 shows the supported plugs for the 3000 W AC power supplies.
Figure 41. 3000-W AC Power Supply Plugs
1. International ( 3000 W) IEC 309 (20 A)
2. Europe (3000 W) CEE 7/7 (16 A)
3. North America (non- locking)(3000)NEMA 6-20 plug (20 A)
4. North America (locking )(3000 W)NEMA L6-20 plug (2 0A)
