IBM SAN192C-6 User Manual

SFP+
Wavelength
(nanometer)
Fiber
Type Core Size (micron)
Baud Rate
(GBd)
Cable Distance
9.0 4.25 15.5 mi (25 km)
Table 34. General Specifications for 32 Gbps Fibre Channel SFP+ Transceivers (continued)
Environmental and Power Requirements for 32 Gbps Fibre Channel SFP+
Transceivers
Table 35 on page 146 provides the power specification for the 32 Gbps Fibre Channel SFP+ transceivers.
Average
Transmit
Power (dBm)
Average
Receive Power
(dBm) Fiber Loss Budget (dBm)
SFP+ Max Min Max Min OM2 OM3 OM4 OM5
FC
32Gb
SW
SFP+
2.0 -6.2 2.0 -8.2 1.68 (8Gbps)
1.63 (16Gbps)
2.02 (32Gbps)
2.04 (8Gbps)
1.86 (16Gbps)
1.86 (32Gbps)
2.04 (8Gbps)
1.95 (16Gbps)
1.86 (32Gbps)
2.04 (8Gbps)
1.95 (16Gbps)
1.86 (32Gbps)
FC
32Gb
10km
LW
SFP+
2.0 -5.0 2.0 -11.4 6.4 (8 Gbps)
6.4 (16 Gbps)
6.4 (32 Gbps)
FC
32Gbps
Fibre
Channel
ELW
SFP+
2.0 -5.0 2.0 -11.4 10 (16 Gbps)
Table 35. Specification for 32 Gbps Fibre Channel SFP+ Transceivers
Table 36 on page 146 provides the environment specification for the 32 Gbps Fibre Channel SFP+
transceivers.
Operating Storage
SFP+ Maximum Minimum Maximum Minimum
FC 32Gb SW SFP+ 40° C 0° C 70° C -40° C
FC 32Gb 10km LW SFP+ 40° C 0° C 70° C -40° C
FC 32 Gbps Fibre Channel ELW SFP
+
40° C 0° C 70° C -40° C
Table 36. Environmental Specifications for 32 Gbps Fibre Channel SFP+ Transceivers
For information about safety, regulatory, and standards compliance, refer to IBM Systems Safety Notices.
146IBM Storage Networking SAN192C-6, SAN384C-6 and SAN768C-6: SAN192C-6, SAN384C-6 and
SAN768C-6 Installation, Service, and User Guide
