Appendix D. IBM c-type SAN Director Accessory Kit
Contents
This appendix lists and illustrates the IBM c-type SAN Director accessory kit contents. (See Table 49 on
page 161)
Illustration Description Quantity
Support rack-mount bracket
kit (includes the following
parts)
1 kit
12-24 x 3/4-in. Phillips
screws
20 per kit
M6 x19-mm Phillips screws 20 per kit
10-32 x 3/4-inch screws 20 per kit
Support rack-mount bracket 2 per kit
Console cable connector
kit (includes the following
parts)
2 kits
RJ-45 rollover cable 1 per kit
DB-9F/RJ-45F PC terminal 1 per kit
RJ-45/DSUB F/F adapter 1 per kit
R-J45/DSUB R/P adapter 1 per kit
DSUB screw lock kit 1 per kit
Ground lug kit (includes the
following parts)
1 kit
Two-hole lug 1 per kit
M4 x 8-mm Phillips pan-
head screws
2 per kit
ESD wrist strap 1 per kit
Table 49. IBM c-type SAN Director Accessory Kit Contents
©
Copyright IBM Corp. 2019, 2021 161
