Figure 88. Example of SAS cables routed through the cable management arms
9. When both ends of a SAS cable are correctly connected, the green link-LED next to the connected SAS
ports are lit.
For example, Figure 89 on page 78 shows the LEDs of expansion canister 1 on a 2076-92F expansion
enclosure. The SAS cable is successfully inserted in to port 1 (input); port 2 (output) does not contain a
SAS cable.
Figure 89. SAS cable correctly inserted into the SAS port
78
Storwize V7000 : Gen3 Quick Installation Guide for MTM 2076-724, 2076-U7B, 2076-12F, 2076-24F, and
2076-92F
