⢠3 Rack mounting screw hole
3. Ensure that the appropriate bracket pins are installed in the front and rear bracket of each rail.
Each rail comes with four medium pins preinstalled (two in the front bracket and two in the rear
bracket). Large pins are provided separately. Use the pins that are appropriate for the mounting holes
in your rack, as described in Table 7 on page 14.
Table 7. Selecting bracket pins for your rack
Mounting holes Bracket pins
Round,
unthreaded
Use the preinstalled medium pins.
Square Unscrew the medium pins and replace with the large pins that are supplied with
the rails.
4. At each end of the rail, grasp the tab 1 and pull îłrmly to open the hinge bracket.
See Figure 10 on page 14.
Figure 10. Opening the hinge brackets
5. Align the holes in the rail bracket with the holes on the front and rear rack cabinet flanges.
Ensure that the rails are aligned on the inside of the rack cabinet.
6. On the rear of the rail, press the two bracket pins into the holes in the rack flanges.
7. Close the rear hinge bracket to secure the rail to the rack cabinet flange.
See Figure 11 on page 15 .
14
Storwize V7000 : Gen3 Quick Installation Guide for MTM 2076-724, 2076-U7B, 2076-12F, 2076-24F, and
2076-92F
