Figure 120. Installing the display panel assembly
3. Insert the display panel assembly until it clicks into position.
4. Replace the top cover, as described in “Installing or replacing the top cover: 2076-92F ” on page 62.
5. Ensure the LEDs on the display panel are lit correctly. See “ Storwize V7000 2076-92F expansion
enclosure LEDs and indicators” on page 116 for details.
Removing the support rails: 2076-92F
You can remove the support rails for the 2076-92F expansion enclosure.
About this task
This task assumes the following conditions:
• The cable management arm is removed, as described in “Removing or moving the cable-management
arm: 2076-92F ” on page 54.
• The expansion enclosure is removed from the rack, as described in “Removing an expansion enclosure
from a rack: 2076-92F ” on page 83.
Procedure
1. Remove the two screws that attach the outer rail section to the front bracket assembly, as shown in
Figure 121 on page 109.
Figure 121. Remove the rail assembly from the front frame bracket
2. Remove the rail section by pulling it away from the front bracket, as shown in Figure 121 on page 109.
3. Remove the two screws that attach the inner rail section to the rear bracket, as shown in Figure 122 on
page 109.
Figure 122. Remove the rail assembly from the rear frame bracket
