• At least three persons are required to move the enclosure while it is in the rack (if you are moving the
enclosure off the rails). Even after the drives, power supply units, secondary expander modules,
canisters, fans, and top cover are removed, the enclosure weighs approximately 43 kg (95 lbs).
• To maximize rack stability, always install the expansion enclosure in the lowest possible position in the
rack.
Weight of expansion enclosure parts
Table 8 on page 28 summarizes the weight and quantity of the parts (FRUs) that are shipped with the 5U
expansion enclosure.
Table 8. Weight of expansion enclosure parts
FRU
description
FRU part
number
Weight per unit
Quantity
shipped
Total weight
kg lbs kg lb
Enclosure
FRU
01LJ607
(replaces
enclosure
FRU P/N
01LJ112)
42.5 93.696 1 42.500 93.696
Rail kit 01LJ114 9.231 20.351 1 9.231 20.351
Front fascia
(4U front
cover)
01LJ116 0.303 0.668 1 0.303 0.668
Display panel
assembly
01LJ118 0.020 0.044 1 0.020 0.044
PSU fascia
(1U cover)
01LJ120 0.010 0.022 1 0.010 0.022
Power supply
unit (PSU)
01LJ122 3.335 7.352 2 6.670 14.705
Secondary
expansion
module
01LJ860 (for
use with
enclosure
FRU P/N
01LJ607)
01LJ124 (for
use with
enclosure
FRU P/N
01LJ112)
0.826 1.821 2 1.652 3.642
Fan module 01LJ126 0.890 1.962 4 3.560 7.848
Expansion
canister
01LJ128 1.588 3.501 2 3.176 7.002
Cable
management
arm (lower
and upper
arms)
01LJ130 1.373 3.027 1 1.373 3.027
Top cover 01LJ132 3.720 8.201 1 3.720 8.201
28 Storwize V5100 : Quick Installation Guide for MTM 2078-424, 2078-12F, 2078-24F, 2078-92F, and 2078-
