Table 9. Weight of expansion enclosure parts (continued)
FRU
description
FRU part
number
Weight per unit
Quantity
shipped
Total weight
kg lbs kg lb
Fan interface
board
01LJ134 0.118 0.260 1 0.236 0.260
Weight of expansion enclosure SAS drives
The SAS drives are shipped in a separate package from the 5U expansion enclosure. The enclosure can
support up to 92 SAS drives; however, the quantity varies depending on the number of drives ordered.
Table 10 on page 36 summarizes the weights of the SAS drives that are supported in the 5U expansion
enclosure. Storwize V7000 Gen2+ systems that are running software level 7.8 can support the 5U
expansion enclosure.
Table 10. Weight of expansion enclosure drives
FRU description FRU part number
Approximate weight per unit
kg lb
600 GB 15 K 2.5-inch
hard disk drive
01LJ061 0.304 0.670
1.2 TB 10 K 2.5-inch hard
disk drive
01LJ062 0.304 0.670
1.8 TB 10 K 2.5-inch hard
disk drive
01LJ063 0.304 0.670
6 TB 7.2 K 3.5-inch Near-
Line SAS hard disk drive
01LJ064 0.876 1.931
8 TB 7.2 K 3.5-inch Near-
Line SAS hard disk drive
01LJ065 0.876 1.931
10 TB 7.2 K 3.5-inch
Near-Line SAS hard disk
drive
01LJ066 0.876 1.931
1.6 TB 2.5-inch tier 0
flash drive
01LJ067 0.224 0.494
3.2 TB 2.5-inch tier 0
flash drive
01LJ068 0.224 0.494
1.92 TB 2.5-inch tier 1
flash drive
01LJ069 0.224 0.494
3.84 TB 2.5-inch tier 1
flash drive
01LJ070 0.224 0.494
7.6 8 TB 2.5-inch tier 1
flash drive
01LJ071 0.224 0.494
15.36 TB 2.5-inch tier 1
flash drive
01LJ072 0.224 0.494
Weight increases as FRUs are installed
The 5U expansion enclosure supports up to 92 SAS drives. As Table 11 on page 37 shows, substantial
weight is added to the enclosure when all drives are installed.
36
Storwize V7000 : Gen3 Quick Installation Guide for MTM 2076-724, 2076-U7B, 2076-12F, 2076-24F, and
2076-92F
