Figure 105. Secondary expander module connectors
5. Place the secondary expander module in a safe location, as shown in Figure 106 on page 96.
Figure 106. Secondary expander module removed from the enclosure
6. If needed, repeat step “2” on page 95 through step “5” on page 96 to remove the other secondary
expander module.
Replace the secondary expansion module
7. To reinstall the secondary expansion module, or replace it with one from FRU stock, follow the
procedure in “Installing or replacing a secondary expander module: 2076-92F ” on page 67.
Removing an expansion canister: 2076-92F
You can remove the expansion canisters in a 2076-92F expansion enclosure.
Before you begin
Important: You can remove an expansion canister without powering off the expansion enclosure.
However, to maintain operating temperature, perform the following tasks.
