6. Place the enclosure back in the rack, as described in “Installing or replacing an expansion enclosure
in a rack: 2076-92F ” on page 50
7. Replace each of the fan modules. Follow the procedure that is described in “Installing or replacing a
fan module: 2076-92F ” on page 79.
8. Replace the drives, secondary expander modules, and other heavy FRUs that were removed before
the enclosure was removed from the rack.
9. Replace the top cover, as described in “Installing or replacing the top cover: 2076-92F ” on page 62.
10. Reconnect power to the enclosure, as described in “Powering on the optional 2076-92F expansion
enclosures” on page 112.
Removing an expansion enclosure from a rack: 2076-92F
You might need to slide the 2076-92F expansion enclosure out of the rack to apply service. For some
tasks, you might need to completely remove the expansion enclosure from the rack.
Before you begin
DANGER: Multiple power cords. The product might be equipped with multiple power cords. To
remove all hazardous voltages, disconnect all power cords. (L003)
Use the reference numbers in parentheses at the end of each notice (for example, D005) to nd the
matching translated notice in IBM Storwize V7000 Safety Notices.
DANGER:
Observe the following precautions when working on or around your IT rack system:
Chapter 2. Installing the system hardware 83
