Figure 32. Example of the required rack space
7. Repeat steps â5â on page 27 through â6â on page 28 to install the opposite rail.
8. Install the expansion enclosure in the rack, as described in âInstalling or replacing an expansion
enclosure in a rack: 2076-92F â on page 50.
Installing an optional 5U SAS expansion enclosure
Before you install the optional 5U SAS expansion enclosure, review the following guidelines:
The 2076-92F expansion enclosure is supported on Storwize V7000 2076-724 and systems that have
Spectrum Virtualize 8.2.0 or later with the latest îłx packs. If the system is not running that level of
software, do not connect it to a 2076-92F enclosure.
Safety notices and considerations: 2076-92F
Before you install, service, or move the expansion enclosure, always read and follow the safety notices
and guidelines.
Safety notices
Use the reference numbers in parentheses at the end of each notice (for example, D005) to îłnd the
matching translated notice in IBM Storwize V7000 Safety Notices.
DANGER:
DANGER: Serious injury or death can occur if loaded lift tool falls over or if a heavy load
falls off the lift tool. Always completely lower the lift tool load plate and properly secure the load
on the lift tool before moving or using the lift tool to lift or move an object. (D010)
DANGER: Multiple power cords. The product might be equipped with multiple power cords. To
remove all hazardous voltages, disconnect all power cords. (L003)
Chapter 2. Installing the system hardware 29
