Figure 109. Fan module LED
You can also issue the lsenclosurefanmodule command to display the status of the fan modules.
2. Press the release tab on the fan module, as Figure 110 on page 99 shows.
Figure 110. Fan module release tab
3. Use the handle to pull the fan module out of the expansion enclosure chassis, as shown in Figure 111
on page 100.
Chapter 2. Installing the system hardware
99
