Table 8. Parts listing, Type 5462 (continued)
Index Description
CRU part
number (Tier 1)
CRU part
number (Tier 2)
NVIDIA Grid K2 (Actively Cooled) 90Y2395
NVIDIA Tesla K40c 90Y2408
Security bezel 00FK615
MISC KIT 00KF419
Slide kit 00KA592
Cable management arm (CMA) 00KA594
Label, chassis 00KF412
Labels, system service and FRU/CRU (2.5-inch) 00KF413
Labels, system service and FRU/CRU (3.5-inch) 00KF414
Microprocessor installation tool 00AE535
Universal slides kit 00KA593
Alcohol wipes 59P4739
Structural parts
Structural parts are not covered by the IBM Statement of Limited Warranty. You
can place an order on the structural parts from the IBM retail store.
The following structural parts are available for purchase from the retail store.
Table 9. Structural parts, Type 5462
Index Description Part number
Chassis, 2.5-inch HDD model 00KF407
Chassis, 3.5-inch 8 HDD model 00KF408
Chassis, 3.5-inch 12 HDD model 00KF409
35 Top cover (2.5-inch model and 3.5-inch 8 HDD model) 00KF404
35 Top cover (3.5-inch 12 HDD model) 00KF405
To order a structural part, complete the following steps:
Note: Changes are made periodically to the IBM website. The actual procedure
might vary slightly from what is described in this document.
1. Go to http://www.ibm.com.
2. From the Products menu, select Upgrades, accessories & parts.
3. Click Obtain maintenance parts; then, follow the instructions to order the part
from the retail store.
If you need help with your order, call the toll-free number that is listed on the
retail parts page, or contact your local IBM representative for assistance.
128 System x3650 M5 Type 5462: Installation and Service Guide
