Removing the security bezel
Use this information to remove the security bezel.
About this task
To remove the security bezel, complete the following steps.
Procedure
1. Read the safety information that begins on “Safety” on page vii and
“Installation guidelines” on page 283.
2. Unlock the security bezel, if needed.
3. ▌1▐Press the release latch and ▌2▐rotate the security bezel to disengage the
security bezel from the chassis.
4. If you are instructed to return the security bezel, follow all packaging
instructions, and use any packaging materials for shipping that are supplied to
you.
Replacing the security bezel
Use this information to replace the security bezel.
About this task
To replace the security bezel, complete the following steps:
Procedure
1. Read the safety information that begins on “Safety” on page vii and
“Installation guidelines” on page 283.
2. ▌1▐Carefully insert the right end of the security bezel into the slots along the
right side of the chassis.
3. ▌2▐Rotate the security bezel until the other side clicks into place on the chassis.
Release latch
Security bezel
Figure 213. Security bezel removal
Chapter 5. Removing and replacing components 257

IBM System x3650 M5 Specifications

General

Processor Cores	Up to 22 cores per processor
Memory Slots	24 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon E5-2600 v3/v4
Memory	Up to 1.5 TB (24x 64 GB LRDIMMs)
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	4x 1 GbE ports standard, optional 10 GbE
Power Supply	Up to 2x redundant hot-swap 550W, 750W, or 900W power supplies
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	Integrated Management Module (IMM) v2.1
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
