IBM System x3650 M5 User Manual

14. Turn on the peripheral devices and the server.
Removing a USB embedded hypervisor flash device
Use this information to remove a USB embedded hypervisor flash device.
About this task
To remove a USB hypervisor flash device, complete the following steps:
Procedure
1. Read the safety information that begins on “Safety” on page vii and
“Installation guidelines” on page 283.
2. Turn off the server and peripheral devices and disconnect the power cords.
3. Remove the top cover (see “Removing the top cover” on page 146).
4. Remove the flash device:
a. Unlock the retention latch on the USB connector by pushing down the blue
locking collar.
b. Grasp the flash device and pull to remove it from the connector.
5. If you are instructed to return the flash device, follow all packaging
instructions, and use any packaging materials for shipping that are supplied to
you.
USB embedded
hypervisor
flash device
Lockbar
Figure 187. USB hypervisor flash device removal
Chapter 5. Removing and replacing components 239

IBM System x3650 M5 Specifications

General

Processor Cores	Up to 22 cores per processor
Memory Slots	24 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon E5-2600 v3/v4
Memory	Up to 1.5 TB (24x 64 GB LRDIMMs)
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	4x 1 GbE ports standard, optional 10 GbE
Power Supply	Up to 2x redundant hot-swap 550W, 750W, or 900W power supplies
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	Integrated Management Module (IMM) v2.1
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
