12x3.5-inch drive model
The internal routing for the 12x3.5-inch drive model cables.
The following illustration shows the internal routing for the 12x3.5-inch drive
model cables.
12x3.5-inch hot-swap hard disk drive model
v 12x3.5-inch hot-swap hard disk drive
SAS signal cable
Power / configuration
cable
SAS 0 SAS 1
Figure 66. 8x3.5-inch hot-swap hard disk drives cabling
144 System x3650 M5 Type 5462: Installation and Service Guide
