Replacing a USB embedded hypervisor flash device
Use this information to replace a USB embedded hypervisor flash device.
About this task
To install a USB hypervisor flash device, complete the following steps:
Procedure
1. Read the safety information that begins on “Safety” on page vii and
“Installation guidelines” on page 283.
2. Turn off the server and peripheral devices and disconnect the power cords.
3. Remove the top cover (see “Removing the top cover” on page 146).
4. Remove the riser-card assembly (see “Removing a riser-card assembly” on page
180).
5. Install the flash device:
a. Align the flash device with the connector on the system board and push it
into the USB connector until it is firmly seated.
b. Pull up the blue locking collar to lock the flash device into the USB
connector.
6. Reconnect the power cords and any cables that you removed.
7. Replace the top cover (see “Replacing the top cover” on page 147).
8. Slide the server into the rack.
9. Turn on the peripheral devices and the server.
USB embedded
hypervisor
flash device
Lockbar
Figure 188. USB hypervisor flash device installation
240 System x3650 M5 Type 5462: Installation and Service Guide
