8x2.5-inch hot-swap hard disk drive model
v 8x2.5-inch hot-swap hard disk drive
SAS signal cable
Power / configuration
cable
Figure 50. 8x2.5-inch simple-swap hard disk drive with software RAID cabling
2.5-inch HDD hot-swap backplane
Power / configuration cable
SAS signal cable
SAS 0
SAS 1
Figure 51. Cable connection
134 System x3650 M5 Type 5462: Installation and Service Guide
