5. Loosen the thumbscrew that is used to secure the media cage onto the server.
6. Carefully push the media cage out of the server and set it aside.
7. If you are instructed to return the media cage, follow all of the packaging
instructions, and use any packaging materials for shipping that are supplied to
you.
Thumbscrew
Figure 101. Thumbscrew
Media cage
Figure 102. Media cage removal
Chapter 5. Removing and replacing components 177
