6. Press down the HDD kit firmly until the HDD kit is fully seated in the
connector on the system board.
7. Replace the top cover (see “Replacing the top cover” on page 147).
8. Slide the server into the rack.
9. Reconnect the power cords and any cables that you removed.
10. Turn on the peripheral devices and the server.
SAS signal cable
3.5" hard disk drive cage
Figure 137. 3.5-inch rear two hard-disk-drive kit cable routing
Chapter 5. Removing and replacing components 205
