a. If there is a rubber cover on the battery holder, use your fingers to lift the
battery cover from the battery connector.
b. Use one finger to tilt the battery horizontally out of its socket, pushing it
away from the socket.
Attention: Neither tilt nor push the battery by using excessive force.
c. Use your thumb and index finger to lift the battery from the socket.
Attention: Do not lift the battery by using excessive force. Failing to
remove the battery properly may damage the socket on the system board.
Any damage to the socket may require replacing the system board.
6. Dispose of the battery as required by local ordinances or regulations. See the
IBM Environmental Notices and User's Guide on the IBM Documentation CD for
more information.
Battery
Figure 189. System battery position
Figure 190. System battery removal
242 System x3650 M5 Type 5462: Installation and Service Guide

IBM System x3650 M5 Specifications

General

Processor Cores	Up to 22 cores per processor
Memory Slots	24 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon E5-2600 v3/v4
Memory	Up to 1.5 TB (24x 64 GB LRDIMMs)
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	4x 1 GbE ports standard, optional 10 GbE
Power Supply	Up to 2x redundant hot-swap 550W, 750W, or 900W power supplies
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	Integrated Management Module (IMM) v2.1
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
