IBM System x3650 M5 User Manual

806f011b-2502ffff The connector [PhysicalConnectorElementName] has encountered a configuration error.
(nvDIMM 02 Cable)
Explanation: This message is for the use case when an implementation has detected an Interconnect Configuration
Error.
May also be shown as 806f011b2502ffff or 0x806f011b2502ffff
Severity: Error
Alert Category: Critical - Other
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0266
SNMP Trap ID: 50
Automatically notify Support: Yes
User response: If the specified sensor is front USB connector, reset the front USB cable on the system board. If the
specified sensor is front video connector, reset the front video cable in the system board. If the specified sensor is
PwrPaddle cable, complete the following steps until problem is solved:
1. Reseat the power paddle cable on the system board.
2. Replace the power paddle cable.
3. (Trained technician only) Replace the supercap n. (n = supercap number)
4. (Trained technician only) Replace the system board.
806f011b-2505ffff The connector [PhysicalConnectorElementName] has encountered a configuration error.
(nvDIMM 05 Cable)
Explanation: This message is for the use case when an implementation has detected an Interconnect Configuration
Error.
May also be shown as 806f011b2505ffff or 0x806f011b2505ffff
Severity: Error
Alert Category: Critical - Other
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0266
SNMP Trap ID: 50
Automatically notify Support: Yes
User response: If the specified sensor is front USB connector, reset the front USB cable on the system board. If the
specified sensor is front video connector, reset the front video cable in the system board. If the specified sensor is
PwrPaddle cable, complete the following steps until problem is solved:
1. Reseat the power paddle cable on the system board.
2. Replace the power paddle cable.
3. (Trained technician only) Replace the supercap n. (n = supercap number)
4. (Trained technician only) Replace the system board.
806f011b-2502ffff • 806f011b-2505ffff
Appendix A. Integrated management module II (IMM2) error messages 473

IBM System x3650 M5 Specifications

General

Processor Cores	Up to 22 cores per processor
Memory Slots	24 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon E5-2600 v3/v4
Memory	Up to 1.5 TB (24x 64 GB LRDIMMs)
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	4x 1 GbE ports standard, optional 10 GbE
Power Supply	Up to 2x redundant hot-swap 550W, 750W, or 900W power supplies
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	Integrated Management Module (IMM) v2.1
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
