IBM x3630 M3 7377 User Manual

b. Press the retention latch to disengage the remote battery tray.
The following illustration shows how to remove the bottom remote battery
tray.
1
2
The following illustration shows how to remove the top remote battery tray.
6. Slightly pull apart the clips on the side of the remote battery tray to remove the
ServeRAID controller battery.
Chapter 5. Removing and replacing server components 171

IBM x3630 M3 7377 Specifications

General

Product Family	System x
Machine Type	7377
Max Processors	2
Chipset	Intel 5520
Memory Slots	12 DIMM slots
Processor	Intel Xeon 5600 series
Memory	Up to 192 GB
RAID Support	RAID 0, 1, 10, 5, 50
Network Interface	2 x Gigabit Ethernet
Power Supply	Hot-swap, redundant
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
