2. Reconnect the power cord and any cables that you removed.

3. Install the PCI riser-card assembly (see “Installing the PCI riser-card assembly”

on page 151).

4. Install the cover (see “Installing the cover” on page 146).

5. Slide the server into the rack.

6. Turn on the peripheral devices and the server.

Removing the USB board

To remove the USB board, complete the following steps:

1. Read the safety information that begins on page vii and “Installation guidelines”

on page 133.

2. Turn off the server and peripheral devices, and disconnect the power cord and

all external cables.

3. Remove the cover (see “Removing the cover” on page 145).

4. Remove the screws that secure the USB board to the chassis.

Chapter 5. Removing and replacing server components 179
