IBM x3630 M3 7377 User Manual

6. Slide the cable arm cover into the retention slots and install the screw to
secure it on the side of the chassis.
7. Install the air baffle (see “Installing the air baffle” on page 150).
8. If you have the optional hot-swap rear hard disk drive cage installed, rotate it
down (see “Rotating the optional hot-swap rear hard disk drive cage down” on
page 148).
9. Install the cover (see “Installing the cover” on page 146).
10. Reconnect the external cables; then, reconnect the power cords and turn on
the peripheral devices and the server.
Removing the front USB connector assembly
To remove the front USB connector assembly, complete the following steps:
1. Read the safety information that begins on page vii and “Installation guidelines”
on page 133.
2. Turn off the server and peripheral devices, and disconnect the power cord and
all external cables.
3. Remove the cover (see “Removing the cover” on page 145).
4. Remove the screw from the cable arm cover; then, slide the cable arm cover
towards the rear of the server and set it aside.
Chapter 5. Removing and replacing server components 183

IBM x3630 M3 7377 Specifications

General

Product Family	System x
Machine Type	7377
Max Processors	2
Chipset	Intel 5520
Memory Slots	12 DIMM slots
Processor	Intel Xeon 5600 series
Memory	Up to 192 GB
RAID Support	RAID 0, 1, 10, 5, 50
Network Interface	2 x Gigabit Ethernet
Power Supply	Hot-swap, redundant
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
