Icom IC-9700 Advanced Manual

11-6
11. ABOUT THE DV GATEWAY FUNCTION
D When connecting your device to the Internet using a cellular system
Setting up a network
A Global IP address is required to use the DV
Gateway function.
A Global IP address
A static or dynamic IPv4 Global IP address assigned to your Windows or Android device is needed.
Ask your Internet service provider to provide a Global IP address to your device.
NOTE:
• Turn OFF your Wi-Fi setting when you operate using a cellular system.
• Communication errors may occur when using a cellular system.
• Depending on your contract, you may be charged a large or additional communication fee. Ask your cellular
system company about the content of your contract.
 When using a Windows device, go to “Setting up the RS-MS3W.” (p. 11-10)
 When using an Android device, go to “Setting up the RS-MS3A.” (p. 11-11)
InternetInternet
OPC-2350LU
OPC-2350LU
Needs a Global IP address.
Needs a Global
IP address.
* You can use a cellular system compatible computer.
*

Icom IC-9700 Specifications

General

Receiver Type	Triple conversion superheterodyne
Display	4.3 inch color TFT touch screen
Type	VHF/UHF/1.2GHz All Mode Transceiver
Receiver System	Triple conversion superheterodyne
D-STAR	Yes
Antenna Impedance	50 ohms
Power Supply	13.8V DC ±15%
Frequency Range	144-146 MHz, 430-440 MHz, 1240-1300 MHz
Mode	FM, SSB, CW, AM
Antenna Connector	2m/70cm: SO-239, 23cm: Type-N
Dimensions	240 x 94 x 238 mm
Weight	Approx. 4.7 kg
RF Power Output	2m/70cm: 100W, 23cm: 10W
GPS	Yes (Internal)
Sensitivity	0.18 μV (FM)
