Icom IC-9700 Advanced Manual

4-3
4. MEMORY OPERATION
Copying the Memory channel contents
D Copying to the VFO
1. Push
V/M
to select the Memory mode.
2. Push
kHz
M-CH
.
3. Rotate
MULTI
to select the channel to be copied.
(Example: Memory channel 1)
4. Hold down
V/M
for 1 second.
• A beep sounds and the selected memory contents are
copied to the VFO.
5. Push
V/M
to select the VFO mode.
You can copy a Memory channel contents to the VFO or another memory channel.
D Copying to the another Memory channel
1. Push
V/M
to select the Memory mode.
2. Push
kHz
M-CH
.
3. Rotate
MULTI
to select the channel to be
copied. (Example: Memory channel 3)
4. Open the MEMORY screen.
MENU
»
MEMORY
5. Rotate
MAIN DIAL
to select the channel to write
the copied contents to. (Example: Memory
channel 5)
L Do not rotate
MULTI
. Select the channel by
rotating
MAIN DIAL
.
6. T ouch of the selected channel.
7. Touch “Memory Write.”
8. Touch [ Yes].
• A beep sounds and the selected memory contents are
copied.
9. To close the MEMORY screen, push
EXIT
.

Icom IC-9700 Specifications

General

Receiver Type	Triple conversion superheterodyne
Display	4.3 inch color TFT touch screen
Type	VHF/UHF/1.2GHz All Mode Transceiver
Receiver System	Triple conversion superheterodyne
D-STAR	Yes
Antenna Impedance	50 ohms
Power Supply	13.8V DC ±15%
Frequency Range	144-146 MHz, 430-440 MHz, 1240-1300 MHz
Mode	FM, SSB, CW, AM
Antenna Connector	2m/70cm: SO-239, 23cm: Type-N
Dimensions	240 x 94 x 238 mm
Weight	Approx. 4.7 kg
RF Power Output	2m/70cm: 100W, 23cm: 10W
GPS	Yes (Internal)
Sensitivity	0.18 μV (FM)
