3. VOICE TX MEMORY FUNCTION
3-1
Recording a Voice TX memory
D Playing back
1. On the selected memory’s recording screen,
touch to start playing back without
transmitting.
LTo stop the playback, touch .
While playing
2. To close the VOICE TX screen, push
EXIT
several
times.
You can record up to 8 Voice transmit memories (T1 ~
T8) of up to one and a half minutes in each memory,
onto an SD card. To transmit a recorded content using
a Voice TX memory, rst record the message, as
described below.
L You can record up to 1 and a half minutes in each
memory.
L A user supplied SD card is required to use the Voice TX
memory function.
L You can also transmit the recorded content using an
external keypad.
D Recording
1. Display the VOICE TX screen in the SSB, AM, FM
or DV mode.
MENU
»
VOICE
2. Touch [REC/SET].
3. Touch the “REC” item.
Opens the VOICE TX RECORD screen.
4. Select the desired Voice memory “T1” ~ “T8.
(Example: T1)
TIP: How to clear the recorded content
Touching the Voice memory for 1 second in step 4
to the left, and then touch “Clear” in the Quick
menu.
5. Touch to start recording.
Without holding down [PTT], speak into the
microphone at your normal voice level.
L Previously recorded content is overwritten.
Touch to open
the MIC GAIN
adjustment
window
While Recording
Adjust the Mic
gain so that the
“REC Level”
meter reads less
than 80%
6. Touch to stop recording.
7. To close the VOICE TX screen, push
EXIT
several
times.
