Icom IC-9700 Advanced Manual

4-2
4. MEMORY OPERATION
Entering memory channel contents
1. Push
V/M
to select the VFO mode.
2. Set the frequency and operating mode.
3. Hold down
kHz
M-CH
for 1 second.
“M-CH” is
selected
4. Rotate
MULTI
to select the Memory channel to
enter the contents set in step 2. (Example: 2)
L If “BLANK” is displayed under the selected memory
channel number, it is a blank channel, meaning that
no contents are entered in that channel.
5. Touch the Memory channel number.
6. Touch [MW] for 1 second until BLANK disappears
from below the channel number.
• The contents are entered in the selected Memory
channel, and BLANK is not displayed below the
channel number.
7. To close the VFO/MEMORY screen, push
EXIT
.
The operating frequency, operating mode, IF lter bandwidth, and so on can be entered to each memory channel.
NOTE: New content you enter will overwrite any
content already in the selected memory.

Icom IC-9700 Specifications

General

Receiver Type	Triple conversion superheterodyne
Display	4.3 inch color TFT touch screen
Type	VHF/UHF/1.2GHz All Mode Transceiver
Receiver System	Triple conversion superheterodyne
D-STAR	Yes
Antenna Impedance	50 ohms
Power Supply	13.8V DC ±15%
Frequency Range	144-146 MHz, 430-440 MHz, 1240-1300 MHz
Mode	FM, SSB, CW, AM
Antenna Connector	2m/70cm: SO-239, 23cm: Type-N
Dimensions	240 x 94 x 238 mm
Weight	Approx. 4.7 kg
RF Power Output	2m/70cm: 100W, 23cm: 10W
GPS	Yes (Internal)
Sensitivity	0.18 μV (FM)
