1-10
6
CKY-6614 WSB- Card
106
IEI
®
Technology, Corp.

Redirection after BIOS POST
 Terminal Type
 VT-UTF8 Combo Key Support
These configuration options are discussed below.
 Serial Port Number [COM1]
The Serial Port Number BIOS option allows you to select which serial port will be used for
the remote access.

COM1
(Default) System is remotely accessed through COM1

COM2
System is remotely accessed through COM2
NOTE: Make sure the selected COM port is enabled through the Super I/O configuration
menu.
 Serial Port Mode [115200 8,n,1]
The
Serial Port Mode
designates baud rate through which the console redirection is made.
The following configuration options are available
 115200 8,n,1
(D
EFAULT
)
 57600 8,n,1
 38400 8,n,1

19200 8,n,1
 09600 8,n,1
NOTE:
Identical baud rate setting must be set to the host (a management computer
running a terminal software) and the slave
To Next Page
